With top hole bolt pattern

Throws snow further and faster resulting in less resistance and vehicle wear, and improved fuel economy.

Keep the blade upright and offer ample room for addition of a shock absorber kit, if desired.

Rolls the snow nicely, keeps it down on the blade and away from the vehicle’s windshield.

Back our frictionless poly moldboard with the strength of steel.

Easily locks the blade, power angling and lift frame assembly to mounting kit assembly on vehicle using spring loaded handle.

From 3 steel support structures that run the width of the moldboard.

Provides added resistance to abrasion, water and rust, making our plows virtually maintenance free.

For Extra lift, strength and safety

Improve surface clearance while plowing forward.

Secure the blade to the quadrant and A-frame assembly, eliminating pin seizure, and easing pin replacement.

Specifications

Plow Model	90P	96P	102P	108P
Blade Length	90″	96″	102″	108″
Blade Height	29″	29″	29″	29″
Blade Skin	3/8″ Poly	3/8″ Poly	3/8″ Poly	3/8″ Poly
Trip Springs	4	4	4	4
Reinforced Ribs	7	7	7	7
Lift Cylinder	1 1/2″ x 6″	1 1/2″ x 6″	2″ x 6″	2″ x 6″
Angling Cylinder	1 1/2″ x 10″	1 1/2″ x 10″	1 1/2″ x 10″	1 1/2″ x 10″
Plowing width at full blade angle	78″	83″	88″	94″
Approximate weight	674 lbs	691 lbs	776 lbs	788 lbs
Cutting Edge	1/2″ x 6″ Steel	1/2″ x 6″ Steel	1/2″ x 6″ Steel	1/2″ x 6″ Steel
Mounting Type	Quik*Link™ IV – Detachable	Quik*Link™ IV – Detachable	Quik*Link™ IV – Detachable	Quik*Link™ IV – Detachable

Approximate weight does not include vehicle mounting kit
