| Clearing Width | 78″ |
|---|---|
| Condition | New |
| Cutting Height | 22″ |
| Cutting Width | 7’6″ |
| Hitch | Drive In |
| Main Category | Snowplows |
| Make | Sno-Way |
| Model | 22 7’6″ |
| Other Equipment | Straight Truck Snowplows |
| Series | Tundra Ram Snowplow Series |
| Warranty | 2 years |
Follow Us On
Follow Us On
Most manufacturers treat the small truck as an afterthought and shorten a heavier blade to suit. Sno-Way went the other direction. The company put a plow on a Subaru Brat in 1978 and has spent the decades since refining what a blade for a downsized vehicle actually needs, which is why the 22 reads as a designed product rather than a cut-down one.
At 80 inches wide and 320 pounds, this is the lighter of the two blades in the 22 range. Weight is the number to watch if you are plowing with an SUV, a compact pickup or a half ton that already carries a service body, because front gross axle weight rating is what disqualifies most small vehicles from plow work, not a shortage of engine.
The moldboard is a steel frame carrying a polycarbonate face. Sno-Way originally chose the material so an operator could see through the blade; it stayed because it keeps mass off the front axle without giving up structural rigidity, which is the whole argument for this plow. Shock Killer trip return and Triple Coat paint protection are standard, and the top rail arrives pre-drilled so a deflector goes on later without anyone taking a bit to a new blade.
Take the 6’8″ over the 7’6″ when the vehicle is at the small end of what can carry a plow at all, or when the work is tight: residential driveways with turns in them, parking stalls, anywhere you are steering more than you are pushing. Ten inches of blade is ten inches less to swing around a corner.
If the vehicle can take the weight, note that the 7’6″ version of this same plow adds only ten pounds for those ten inches, which is an unusually cheap trade. Step up to the 26 if you want a taller 26 inch moldboard on the same two blade widths to carry more snow per pass. The 22 DriveWay is the variant to look at for packed residential work, and the 22SKD is the same blade set up for a skid steer or tractor rather than a truck.
| Clearing Width | 69″ |
|---|---|
| Condition | New |
| Cutting Height | 22″ |
| Cutting Width | 68″ |
| Hitch | Drive In |
| Main Category | Snowplows |
| Make | Sno-Way |
| Model | 22 6’8″ |
| Other Equipment | Straight Truck Snowplows |
| Series | Tundra Ram Snowplow Series |
| Warranty | 2 years |
The interesting thing about the wide blade in the 22 range is what it does not cost. Moving from 6’8″ to 7’6″ adds ten inches of moldboard and ten pounds of plow, 320 up to 330. On a vehicle class where every pound lands on a front axle that was never rated for this work, a ten percent gain in blade for a three percent gain in weight is the rare upgrade that does not need arguing about.
Angled 30 degrees, this blade clears 78 inches against the 6’8″ blade’s 69. That nine inch difference is what decides whether a driveway takes three passes or four, and on a long approach or a small commercial lot it compounds across the whole season.
Blade width is not only about how much snow moves per pass. A blade running at an angle needs to be wide enough that the vehicle’s rear tires stay inside the cleared path, and on a full size half ton or a wider SUV the 6’8″ blade starts to give that up on a hard angle. The 7’6″ keeps the truck tracking in what it has already cleared, which matters most on the second and third pass when the windrow is building at the edge.
Everything structural is shared with the rest of the 22 range. Steel frame with a polycarbonate face to keep weight down, 3/8 by 6 inch cutting edge, four vertical and two diagonal ribs behind the moldboard, two trip springs, Shock Killer trip return and Triple Coat paint as standard.
This is the 22 for a full size half ton, a larger SUV, or anyone plowing enough ground that a pass saved is worth having. Drop to the 6’8″ if the vehicle is smaller than a half ton, or if the work is tight enough that maneuvering costs you more time than passes do.
The 26 offers the same 7’6″ width on a 26 inch moldboard if you want more snow carried per pass rather than more width. For packed residential drives there is the 22 DriveWay at this same blade size, and the 22SKD puts the equivalent blade on a skid steer or tractor.
Interest rates vary by person and trailer. All payments are estimates. Tax, title and any other fees are extra.
Recommended for You
Precise Control, Consistent Spreading for Class 6 & 7 Trucks
Maximize productivity on large-scale commercial jobs with the Ice Raven Salt Spreader Series by Sno-Way® V-Box 4300 salt spreader, boasting a massive 4.3 cubic yard capacity designed specifically for Class 6 and 7 trucks. Rely on its robust construction and gain unmatched control over material distribution using the advanced RS controller and patented inverted Vee system for consistent, efficient spreading.
Need more space in your truck bed? Check out our 3 Cubic Yard or 3.5 Cubic Yard models.
The V-box poly hopper is specifically designed to never collapse. This might seem odd but that is the main reason that poly spreaders and sanders don’t last. While we beefed up the construction we added specific tie-down connection points and anti-crush zones. You deserve quality.
Our PATENTED Inverted Vee (NOT NEEDED or AVAILABLE on V-Box 10 and V-Box 500) is actually one of the secrets to the success of this V-Box spreader. The design allows the contractor to dial in the specific amount of material that will drop to the auger BASED on the material they are spreading.
The RS Controller offers Constant Drive and Auto Mode that allow customization of the independent auger and spinner and vibrator in maximizing material distribution. In addition, the controller operates key accessories such as pre-wetting systems and lighting.
The chutes are available in 16” short chute and 29” long chute. Easy on/off stainless steel and roto molded chute has a 16” four flute poly spinner to provide you long life and superior spread pattern up to 30’.
Choose a short chute or long chute to go with your V-Box spreader (not included) See Spec chart for measurements.
RVB4300
4.3 CUBIC YARD
905 lbs.
133
110
57
52
127
12 Volt, 1/3 HP
12 Volt .6HP
16″ Diameter Poly Four Flute
16″ Short Chute, 29″ Long Chute
Steel, E Coat, Powder Coat
standard
standard
standard
standard
standard
optional
optional
optional
RS Digital Control
optional
N/A
Class 6 &7
Precision driven spreader system focused on control, efficiency, and consistency.
Handle the largest commercial jobs with the Ice Raven Salt Spreader Series by Sno-Way® V-box 3500 spreader, built with a robust frame and high-capacity poly hopper suitable for trucks up to Class 7. Leverage the advanced RS Controller and adjustable inverted vee for ultimate control over material flow and achieve consistent spread patterns, powered by heavy-duty, fully enclosed motors.
Need more capacity? Check out our 4.3 Cubic Yard model.
The V-box poly hopper is specifically designed to never collapse. This might seem odd but that is the main reason that poly spreaders and sanders don’t last. While we beefed up the construction we added specific tie-down connection points and anti-crush zones. You deserve quality.
Our PATENTED Inverted Vee (NOT NEEDED or AVAILABLE on V-Box 10 and V-Box 500) is actually one of the secrets to the success of this V-Box spreader. The design allows the contractor to dial in the specific amount of material that will drop to the auger BASED on the material they are spreading.
The RS Controller offers Constant Drive and Auto Mode that allow customization of the independent auger and spinner and vibrator in maximizing material distribution. In addition, the controller operates key accessories such as pre-wetting systems and lighting.
The chutes are available in 16” short chute and 29” long chute. Easy on/off stainless steel and roto molded chute has a 16” four flute poly spinner to provide you long life and superior spread pattern up to 30’.
Choose a short chute or long chute to go with your V-Box spreader (not included) See Spec chart for measurements.
RVB3500
3-1/2 CUBIC YARD
825 lbs.
133
110
48
52
127
12 Volt, 1/3 HP
12 Volt .6 HP
16″ Diameter Poly Four Flute
16″ Short Chute, 29″ Long Chute
Steel, E Coat, Powder Coat
standard
standard
standard
standard
standard
optional
optional
optional
RS Digital Control
optional
N/A
Class 5 & 6
High-Capacity, Precise Control for Commercial Applications
Maximize your commercial spreading operations with the high-capacity Ice Raven Salt Spreader Series by Sno-Way® V-Box 3000 salt spreader, featuring a durable roto-molded hopper mounted on a robust stainless steel frame for lasting performance. Dial in precise material flow with the adjustable inverted vee and command ultimate control using the RS controller for independent auger and spinner speeds, ensuring efficient and consistent coverage.
Need more capacity? Check out our 3.5 Cubic Yard or 4.3 Cubic Yard models.
The V-box poly hopper is specifically designed to never collapse. This might seem odd but that is the main reason that poly spreaders and sanders don’t last. While we beefed up the construction we added specific tie-down connection points and anti-crush zones. You deserve quality.
Our PATENTED Inverted Vee (NOT NEEDED or AVAILABLE on V-Box 10 and V-Box 500) is actually one of the secrets to the success of this V-Box spreader. The design allows the contractor to dial in the specific amount of material that will drop to the auger BASED on the material they are spreading.
The RS Controller offers Constant Drive and Auto Mode that allow customization of the independent auger and spinner and vibrator in maximizing material distribution. In addition, the controller operates key accessories such as pre-wetting systems and lighting.
The chutes are available in 16” short chute and 29” long chute. Easy on/off stainless steel and roto molded chute has a 16” four flute poly spinner to provide you long life and superior spread pattern up to 30’.
Choose a short chute or long chute to go with your v-box spreader (not included) See Spec chart for measurements.
RVB3000
3 CUBIC YARD
445 lbs.
111.6
89
48.5
50.75
104
12 Volt, 1/3 HP
12 Volt 1/2 HP
16″ Diameter Poly Four Flute
16″ Short Chute, 29″ Long Chute
Steel, E Coat, Powder Coat
standard
standard
standard
standard
standard
optional
optional
optional
CLASS 5 Digital 6
optional
N/A
CLASS 5 AND 6
Premium Stainless Steel Spreading for Heavy-Duty Commercial Use
Invest in the ultimate durability with the Ice Raven Salt Spreader Series by Sno-Way® V-Box Stainless Steel 2500 salt spreader, featuring all stainless steel construction from the frame to the hopper for maximum longevity and corrosion resistance on 1-ton and larger trucks. Command precise control over high-capacity spreading operations using the advanced RS controller and inverted Vee design, ensuring efficient application of various materials job after job.
Also available in a lightweight Poly Hopper.
Need more capacity? Check out our 3 Cubic Yard model.
The V-Box Stainless Steel Salt Spreader and Sander is all stainless steel from the custom frame and drive support to the hopper and meant to last. The V-Box stainless steel inside hopper walls are designed for maximum flow of the toughest materials to minimize material bridging.
Our PATENTED Inverted Vee (NOT NEEDED or AVAILABLE on V-Box 10 and V-Box 500) is actually one of the secrets to the success of this V-Box spreader. The design allows the contractor to dial in the specific amount of material that will drop to the auger BASED on the material they are spreading.
The RS Controller offers Constant Drive and Auto Mode that allow customization of the independent auger and spinner and vibrator in maximizing material distribution. In addition, the controller operates key accessories such as pre-wetting systems and lighting.
The chutes are available in 16” short chute and 29” long chute. Easy on/off stainless steel and roto molded chute has a 16” four flute poly spinner to provide you long life and superior spread pattern up to 30’.
Choose a short chute or long chute to go with your V-Box spreader (not included) See Spec chart for measurements.
RVB2500SS
2 1/2 CUBIC YARD
671 lbs.
108.5
85.7
41″ (TOP OF KNOB)
51.8
100.5
12 Volt, 1/3 HP
12 Volt 1/2 HP
16″ Diameter Poly Four Flute
16″ Short Chute, 29″ Long Chute
STAINLESS STEEL
standard
standard
standard
standard
standard
optional
optional
optional
RS Digital Control
optional
N/A
1 TON AND LARGER
Ultimate Control, Consistent Spreading, and Built to Last
Designed for demanding commercial use, the Ice Raven Salt Spreader by Sno-Way® V-Box 2500 salt spreader combines a rugged, corrosion-resistant build with the advanced RS Controller for superior control over material distribution. Achieve consistent spread patterns up to 30 feet and precisely match materials using the adjustable inverted vee, all powered by fully enclosed motors built to withstand harsh conditions.
Also available in a heavy duty Stainless Steel model
Need more capacity? Check out our 3 Cubic Yard model.
The V-Box frame and drive support starts as High Rolled Steel then it is sealed with an Automotive E-Coat Primer and finally finished with Military Grade Powder Coat – we are obsessed with quality.
The V-box poly hopper is specifically designed to never collapse. This might seem odd but that is the main reason that poly spreaders and sanders don’t last. While we beefed up the construction we added specific tie-down connection points and anti-crush zones. You deserve quality.
Our PATENTED Inverted Vee (NOT NEEDED or AVAILABLE on V-Box 10 and V-Box 500) is actually one of the secrets to the success of this V-Box spreader. The design allows the contractor to dial in the specific amount of material that will drop to the auger BASED on the material they are spreading.
The RS Controller offers Constant Drive and Auto Mode that allow customization of the independent auger and spinner and vibrator in maximizing material distribution. In addition, the controller operates key accessories such as pre-wetting systems and lighting.
The chutes are available in 16” short chute and 29” long chute. Easy on/off stainless steel and roto molded chute has a 16” four flute poly spinner to provide you long life and superior spread pattern up to 30’.
Choose a short chute or long chute to go with your V-Box spreader (not included). See Spec chart for measurements.
RVB2500
2 1/2 CUBIC YARD
370 lbs.
111.6
89
41
50.75
104
12 Volt, 1/3 HP
12 Volt 1/2 HP
16″ Diameter Poly Four Flute
16″ Short Chute, 29″ Long Chute
Steel, E Coat, Powder Coat
standard
standard
standard
standard
standard
optional
optional
optional
RS Digital Control
optional
N/A
1 TON AND LARGER
Durable Stainless Steel Spreader
Invest in long-lasting performance with the Ice Raven Salt Spreader Series by Sno-Way 2000S, featuring robust stainless steel construction in the frame, hopper, and drive support for maximum corrosion resistance. Tackle demanding commercial jobs with confidence, utilizing the advanced RS Controller and inverted Vee system for precise control over material flow and spread patterns up to 30 feet.
Also available in a lightweight Poly Body model.
Need more capacity? Check out our 2.5 Cubic Foot model.
The V-Box 2000 Stainless Steel Salt Spreader
The V-Box Stainless Steel Salt Spreader and Sander is all stainless steel from the custom frame and drive support to the hopper and meant to last. The V-Box stainless steel inside hopper walls are designed for maximum flow of the toughest materials to minimize material bridging.
Our PATENTED Inverted Vee (NOT NEEDED or AVAILABLE on V-Box 10 and V-Box 500) is actually one of the secrets to the success of this V-Box spreader. The design allows the contractor to dial in the specific amount of material that will drop to the auger BASED on the material they are spreading.
The RS Controller offers Constant Drive and Auto Mode that allow customization of the independent auger and spinner and vibrator in maximizing material distribution. In addition, the controller operates key accessories such as pre-wetting systems and lighting.
The chutes are available in 16” short chute and 29” long chute. Easy on/off stainless steel and roto molded chute has a 16” four flute poly spinner to provide you long life and superior spread pattern up to 30’.
Choose a short chute or long chute to go with your V-Box spreader (not included) See Spec chart for measurements.
RVB2000
2 CUBIC YARD
600 lbs.
108.5
85.7
38 (TOP OF KNOB)
51.8
100.5
12 Volt, 1/3 HP
12 Volt 1/2 HP
16″ Diameter Poly Four Flute
16″ Short Chute, 29″ Long Chute
STAINLESS STEEL
standard
standard
standard
standard
standard
optional
optional
optional
RS Digital Control
optional
N/A
1 TON AND LARGER
Available for Every Job
