FISHER SNOW PLOW (11) AUTOMATIC WING PLOW XRS (77500)

Product

Blade Construction

  • 29 ½″ tall moldboard available in 8’7″ width
  • 12-gauge, powder coated steel
  • ½” x 6″ high-carbon steel cutting edge with poly wing cutting edges and comes standard to increase the wear resistance of your blade
  • 70-degree attack angle ensures a clean scrape and back drag
  • Easy accessory installation with pre-punched blade



Structural Reinforcement

  • 8 vertical ribs (6 blade ribs and 2 wing ribs) and heavy-duty torsion tube eliminate blade twisting and provide exceptional torsional strength
  • 1” diameter pivot bushing secures the plow in place for proper alignment and reduces stress on the plow assembly

Articulating Wings

The 8’7″ XRS articulating blade extends to 9’8″ with both wings pinned back.



Every FISHER snowplow includes:

minute mount 2 snowplow attachment system

Minute Mount® 2 System

The Minute Mount® 2 attachment system has been engineered for safety, durability, and convenience to make attaching and detaching your plow easier with simple drive-in alignment and connection.

A close-up of a yellow snow plow blade attached to black metal machinery, positioned against a plain, light background with the blade touching the ground.

Trip-Edge Protection

Our industry-leading trip-edge design protects you and your equipment from hidden obstacles. Wing plows feature poly cutting edge for the wings, designed specifically to provide added trip protection.

Hydraulics Thumbnail video image

Hydraulics

We design and manufacture our own hydraulics to ensure the highest standards of performance, quality, and durability when changing the blade position quickly for easy and efficient plowing.

Close-up of a yellow snowplow attached to the front of a truck, pushing a large amount of snow on a winter day. The trucks headlights are on, and snow is piled up along the blade.

Chain Lift Design

The FISHER® chain lift design delivers key performance and reliability advantages, including a cleaner scrape, higher stacking capabilities, and easy recovery in the event of a breakdown.

FleetFlex Electrical System logo in bold, dark gray letters on a white background, with FleetFlex in large text and Electrical System smaller beneath it.

FLEET FLEX Electrical System

The FLEET FLEX electrical system allows plow fleets to use any FISHER® plow on any vehicle for true fleet interchangeability and reliable connections between your vehicle and your equipment.

A black plastic 3-port isolation module labeled ISOLATION MODULE 3-PORT with labeled ports A, B, and C, and a green sticker displaying service and ID numbers.

Isolation Module

An underhood module transfers lights from the vehicle to the plow automatically and improves system reliability while preventing potential electrical system damage in the event of a shorted circuit.

storm guard powder coat for FISHER snowplows

STORM GUARD™ Powder-Coat

The STORM GUARD™ powder-coat with epoxy primer protects against wear and rust. The automated, eight-wheel shot blaster pre-treatment and multi-wash process prepares the blade for ultimate adhesion.

security guard for FISHER snowplow anti-theft

SECURITY GUARD™ Anti-Theft

The exclusive SECURITY GUARD™ anti-theft system is a secure way to electronically lock your plow whenever detached from your vehicle and automatically unlock once connected to your vehicle.





Specification 77500
Moldboard Options Powder-Coated Steel
Blade Type Automatic Winged Blade
Vehicle Compatibility Truck Class 2-5 & Skid-Steers (50 to 70 HP)
Trip Springs 4
Ribs 6 (Blade)
2 (Wings)
Mount Type Oscillating Skid-Steer Mounting Plate OR Minute Mount 2



Price:

Stock No:

XRS 77500
